page 18

T3-T4

Fig. 16a: Posterior-anterior chest radiograph shows a large central bronchogenic carcinoma on the left; questionable involvement of mediastinum or vascular structures, T3 or T4.

Fig. 16b: Computed tomographic scan of the chest shows that the tumor totally surrounds and compresses the left pulmonary artery and extends into the Intrapericardial portion of the vessel. Involvement of the Intrapericardial portions of the pulmonary arteries should be classified T4; tumor extension involving the vessels distal to the pericardium is T3. (see p. 53)
